Быстрый просмотр
With the help of the RT-F1300N rotary table, round shapes can be dispensed conveniently into hard-to-reach places. Easily adjustable, tiltable Z-axis provides controlled, fixed-angle dosing rotation. For example, the material to be dosed may be applied to a vertical inner or outer wall of a cylindrical component. The turntable is used for dosing adhesives, silicones, greases and lubricants and is fully programmable in terms of speed, wheel diameter, cycle and dosing time. VIEWEG's wide range of accessories allows the installation of cartridges and valves in the Z direction. VIEWEG also offers a range of dispensers, valves and valve controllers. We will be happy to advise you.
Быстрый просмотр
The Hanningfield Uni-Dust centrifugal precipitator is specifically designed to recover waste powder from in-house pharmaceutical processes such as compression and encapsulation, typically capturing 90 to 99.9% of waste powder. - Highly efficient design covering 90 - 99.9% - Prevents clogging and replacement of expensive filters in a central vacuum system or vacuum cleaner - Improved lot alignment and product recovery - Virtually zero maintenance costs with no moving parts or filters - Reconstituted powder can be re-introduced - minimizing material wastage and saving money
| Прибл. вес | 12 кг |
| Контактирующие c продуктом детали | нержавеющая сталь 316L |
| Не контактирующие с продуктом детали | нержавеющая сталь 304 |
| Диаметр корпуса циклона | 101.6 мм |
| Диаметр впускной/выпускной трубы | 50.8 мм |
| Диаметр выхода продукта | 63.5 мм |
Characteristics
Быстрый просмотр
The RINA SRP models are vertical decanter industrial centrifuges with a tubular drum, rotating at a very high speed (15.000G mini). They are used for solid-liquid separation (C version) or liquid-liquid separation (S version).
| Ø барабана (мм) | 125 |
| Высота барабана, мм | 735 |
| Объем лт . | 8 |
| Скорость об / мин | 14700 |
| Мощность мотора, л.с. | 5 |
| Ø барабана, дюйм | 4.92 |
| Высота барабана в дюймах | 29 |
| Объем Cu. Фут . | 0,27 |
Characteristics
Быстрый просмотр
MACFUGE manual discharge disc centrifuges are designed and built to separate mixtures of liquids of varying specific gravity and solids. These machines are simple and offer a variety of configurations to suit process requirements.
| Бак | Скорость вращения 7,800 об / мин |
| Двигатель | Мощность 5,5 кВт |
| Размеры | 500 X 900 X в. Мм. 1050 |
Characteristics
Быстрый просмотр
The SG Series models are designed to insert a desiccant into cans. Desiccant sachets fed from a roll are detected by optical sensors, cut to length and inserted into jars. It is possible to insert different desiccants without having to change format parts.
| Другие настройки | 2 |
| Размеры | 1500 (Д) x 800 (Ш) x 1800 (В) мм. |
| Вес нетто | 150 кг |
| - Производительность | Макс. 120 банок в минуту в зависимости от размера банки и скорости подачи |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм. |
| Размер пакета с осушителем | до 50 (Ш) x 100 (Д) мм. |
Characteristics
Быстрый просмотр
IC-120 is a continuous capping machine for cans. The lids are oriented and fed by a vibrating bunker on a signal from a sensor that detects the can. The screwing station closes cans with lids using rotating capping heads with a given torque.
The model is designed to close containers with both screw-on and tight-fitting lids. Containers with misaligned, skewed or missing lids are automatically rejected.| Другие настройки | 2 |
| Размеры | 2400 (Д) x 1000 (Ш) x 1800 (В) мм |
| Вес нетто | 900кг |
| - Производительность | Макс. 100 банок в минуту в зависимости от формы и размера крышки |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм |
| Размеры крышек | диаметр 30-99 мм, высота 10-30 мм |
Characteristics
Быстрый просмотр
volumetric dosing of 2k components, 0.03 cu. see controller included
| Вес | 1,9 г |
| Температура | 10 ° C - 40 ° C |
| Напряжение | 18-24 В постоянного тока |
| Технические подробности | 7 кг |
| Вход материала | 1/4 дюйма |
| Материал смачиваемых частей | анодированный алюминий |
| Объем дозирования (мин.) | 0,03 мл |
| Скорость потока | 1) |
| Давление жидкости (макс.) | 40 бар |
| Рабочее давление (мин.) | 0 бар |
| Выход материала | Смесительная трубка M-50D |
| Технические особенности | - Точное дозирование по объему |
| Эксплуатация | электрическая |
Characteristics
Быстрый просмотр
The Ultra Mixer series are vacuum homogenizers. The main functions are homogenization, emulsification, mixing and defoaming. A mixing part that provides high speed shear for homogenization and a counter-rotating scraper part that mixes the product at low speed. Heating, cooling and vacuum devices are designed to work with various products in the cosmetic, pharmaceutical, food and chemical industries. The high power homogenizer, mounted on the bottom of the tank, works efficiently with small batches. Typically used for low to high viscosity products.
| Объем реактора | Объем: 3 - 5 л; |
| Мощность двигателя | 0,37 кВт |
| Размеры (Д x Ш x В) | 1,100 x 650 x 1,760 (1,900) мм |
Characteristics
Быстрый просмотр
volumetric dosing and mixing of 2k components of 0.01 cu. see including controller
| Вес | 1,6 г |
| Температура | 10 ° C - 40 ° C |
| Напряжение | 18-24 В постоянного тока |
| Технические подробности | 5 кг |
| Вход материала | 1/8 дюйма |
| Материал смачиваемых частей | анодированный алюминий |
| Объем дозирования (мин.) | 0,008 мл |
| Материал на выходе | Люэр-Лок |
| Скорость потока | 1) |
| Давление жидкости (макс.) | 20 бар |
| Рабочее давление (мин.) | 20 бар |
| Технические особенности | - Точное дозирование по объему |
| Эксплуатация | электрическая |
Characteristics
Быстрый просмотр
The fluidization hopper is equipped with a fluidization cone made of a special porous material. The product flow in the form of a sticky or non-volatile powder is optimized by the compressed gas that passes through the pores of the cone. When handling flammable products, an inert gas can be used.
Быстрый просмотр
The LP03 freeze dryer is designed to produce pilot batches of product before scaling up the production process and helps to determine the optimal conditions and parameters to achieve the ideal drying result. Optionally, the model can be equipped with automatic sealing of vials under vacuum.
| Другие настройки | 2 |
Characteristics
Быстрый просмотр
The SC-40 reciprocating machine is designed to close cans with lids. The lids are oriented and fed by a vibrating bunker on a signal from a sensor that detects the can. The screwing station closes cans with lids using rotating capping heads with a given torque.
The model is designed to close containers with both screw-on and tight-fitting lids. Containers with misaligned, skewed or missing lids are automatically rejected.| Другие настройки | 2 |
| Размеры | 2840 (Д) x 1300 (Ш) x 2050 (В) мм |
| Вес нетто | 1300кг |
| - Производительность | Макс. 40 банок в минуту в зависимости от формы и размера крышки |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм |
| Размеры крышек | диаметр 30-100 мм, высота 10-30 мм |
Characteristics
Быстрый просмотр
Agitator impeller lift is an option for the PTK high speed mixer. After the WIP process, the air cylinder raises the impeller to facilitate drying.
Быстрый просмотр
High-precision, wear-resistant ceramic metering pumps with a low thermal expansion coefficient handle aggressive, corrosive or abrasive media and meet the highest standards of the pharmaceutical industry, have excellent resistance to almost all chemicals
| Другие настройки | 2 |
Characteristics
Быстрый просмотр
Dosing is a common practice in the pharmaceutical industry where active pharmaceutical ingredients (APIs) and powder excipients must be precisely dosed into IBCs (bins). Often these activities are still performed openly inside a laminar flow cabin, causing problems for the operator due to difficult manual handling, exposure to dust and high risks of cross contamination. Dec's safe bin filling solution typically includes a PTS Powder Transfer System® mounted on the container being filled, avoiding gravity loading and the need for a second floor, work platform or drum hoist/tilt column. The PTS can be equipped with an optional breathing filter, allowing the IBC to release pressure during filling without polluting the environment and exhaust system. Thanks to this solution, the IBC (bin) does not require additional attachments that can be installed on the floor scales for final weight control.
Быстрый просмотр
MACFUGE manual discharge disc centrifuges are designed and built to separate mixtures of liquids of varying specific gravity and solids. These machines are simple and offer a variety of configurations to suit process requirements.
| Бак | Скорость вращения 4.700 об / мин |
| Двигатель | Мощность 22 кВт |
| Размеры | мм 950 X 1500 X в. 2100 |
Characteristics
Быстрый просмотр
Hanningfield Uni-Vac vacuum conveyors are designed as a safe and convenient way to transport powder. - Automate and speed up the loading process - Dust-proof transfer of material from A to B - Reduced manual handling (horizontal and vertical transfer) - Can be installed in line for subsequent feeding (gravity feeding or vacuum pumping)
| Объем | Емкость бункера: 30 литров |
| Контактирующие c продуктом детали | нержавеющая сталь 316L |
| Не контактирующие с продуктом детали | нержавеющая сталь 304 |
| Диаметр бункера | 254 мм |
| Высота бункера | 1090 мм |
| Стандартный диаметр шланга | 1.5 дюйма |
Characteristics
Быстрый просмотр
COVISS is a tablet/capsule visual inspection system that has been designed to the highest regulatory standards required for visual inspection. COVISS detects serious defects in products, incl. chipped, dented capsules, or black spots in the softgels in the pill counter as they move through the vibrating chutes. Upon detection of a can containing any defective product, it is removed from the conveyor. With an amazingly simple setup method and the ability to integrate with any brand of existing tablet counter, COVISS is a must-have control system for all tablet/capsule packaging operations. 21 CFR Part 11 compliance available
Быстрый просмотр
MACFUGE manual discharge disc centrifuges are designed and built to separate mixtures of liquids of varying specific gravity and solids. These machines are simple and offer a variety of configurations to suit process requirements.
| Бак | Скорость вращения 9.600 об / мин |
| Двигатель | мощность 4 кВт |
| Размеры | мм 500 X 800 X в. 1000 |
Characteristics
Быстрый просмотр
The Hanningfield CapsuJet Capsule Transfer System is a proven method for gently transporting hard shell gelatin capsules. - Eliminates manual operation - Ensures the filling machine never runs dry - Gentle handling with virtually zero capsule damage - Fits all sizes of hard shell capsules
| Объем | Стандартный объем бункера: 200 л / 100,000 капсул круглой формы |
| Прибл. вес | 150 кг |
| Контактирующие c продуктом детали | нержавеющая сталь 316L |
| Не контактирующие с продуктом детали | нержавеющая сталь 304 |
| Применение | перенос пустых капсул |
| Максимальное расстояние вертикальной транспортировки | 10 м |
| Максимальное расстояние горизонтальной транспортировки | 5 м |
| Прибл. размеры | (В) 1180 мм x (Ш) 760 мм x (Д) 1215 мм |
Characteristics
