manual depacking station Manual depacking station for removing outer packaging as well as Tyvek lids and liners from trays and nests. After unpacking - nests are manually placed on a holding platform so that nested objects can be removed from the nest by the robotic arm of the manipulator - vials are manually fed from the trays to the turntable Optional equipment: - With a hole in the top of the reject machine, including a reject container - Four ports for gloves, including two pairs of hypalon gloves.
Быстрый просмотр
RINA flash dryer models operate continuously by spraying slurries or dosing wet solids in a toroidal or straight drying chamber. This technological solution is particularly recommended for products that can be dried at high temperature to flash the liquid.
| Испарение воды кг / ч | 1000 |
| Производительность (влажный продукт) кг / ч | 750 До 1500 |
| Сухой продукт кг / ч | 1250 |
Characteristics
Быстрый просмотр
Pharmabios bioreactors are specially prepared for the pharmaceutical and biopharmaceutical industries. Special attention is paid to the cleanliness and sterilization of the bioreactor in the design to ensure no contamination between batches. The operation of the bioreactor is fully automated by means of a PLC installed in a stainless steel electrical cabinet, where all process parameters can be monitored and recorded. Bioreactors Pharmabios also have several sets of valves to regulate the flow of gases inside the bioreactor, addition of nutrient medium, product yield, etc. The main advantages of Bioreactors Pharmabios: - Temperature control, mixing speed. Dissolved oxygen concentration, pH, foam, - Compact and optimized design for CIP/SIP, - Various types of microbial growth (aerobic, anaerobic, etc.),
| Объем реактора | 50 л. |
| Объем биореактора (л) | 50 |
| Размеры (мм. ДхШхВ) | 1.500 x 1.500 x 2.000 |
| Потребление электроэнергии (кВт) | 2 |
| Чистый пар (расход / давление) | 0,5 м3 ч / 2 бар. |
Characteristics
Быстрый просмотр
OS Series automatic machines are designed for sticking instructions on lids. The cans are fed by a synchronizing screw and detected by a sensor, after which hot melt adhesive is applied to each lid and a paper instruction is placed on top.
| Другие настройки | 2 |
| Размеры | 2300 (Д) x 1200 (Ш) x 1900 (В) мм |
| Вес нетто | 400 кг |
| - Производительность | Макс. 120 банок в минуту |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм |
| Размеры этикетки | мин. 30x30 мм / макс. 40x60 мм |
Characteristics
Быстрый просмотр
RINA flash dryer models operate continuously by spraying slurries or dosing wet solids in a toroidal or straight drying chamber. This technological solution is particularly recommended for products that can be dried at high temperature to flash the liquid.
| Испарение воды кг / ч | 2500 |
| Производительность (влажный продукт) кг / ч | 2500 До 6500 |
| Сухой продукт кг / ч | 5000 |
Characteristics
Быстрый просмотр
The PI Series machines are designed to insert pieces of paper into filled cans. Sheets from a paper roll are cut to a predetermined length and placed in a container, a rejection system ensures continuous and error-free operation.
| Другие настройки | 2 |
| Размеры | 3600 (Д) x 1080 (Ш) x 2050 (В) мм. |
| Вес нетто | 1000кг |
| - Производительность | Макс. 120 банок в минуту в зависимости от диаметра горлышка банки и скорости подачи |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм. |
| Требования к бумаге | бумага в рулоне (ширина 75 мм, толщина 0,03 мм). |
Characteristics
Быстрый просмотр
RINA flash dryer models operate continuously by spraying slurries or dosing wet solids in a toroidal or straight drying chamber. This technological solution is particularly recommended for products that can be dried at high temperature to flash the liquid.
| Испарение воды кг / ч | 250 |
| Производительность (влажный продукт) кг / ч | 200 До 400 |
| Сухой продукт кг / ч | 255 |
Characteristics
Быстрый просмотр
The FLL60, FKL120, FLL120, FLL201 and FLL401 linear flask filling and capping machines with an innovative transport system are the most modern filling solution for any type of product.
Models FLL60, FKL120, FLL120, FLL201 and FLL401 are also available in different versions such as filling, rubber stoppering and aluminum capping (/GB), only filling and rubber stoppering (/G), Seaming only with aluminum caps (/B), filling and closing with screw caps (/S), snap caps (/AP).| Производительность | 3600 |
| Диаметр объекта | до 68 мм |
| Высота объекта | до 125 мм |
Characteristics
Быстрый просмотр
The Pharmabios CIP, or Cleaning in place, equipment cleaning systems allow the cleaning of production equipment, pipes, fittings and other components in a fully automated way. In the biotechnology industry, where shift work is common, it is important not only to optimize the production process, but also to optimize cleaning cycles to reduce the time interval between batches.
| Размеры (мм. ДхШхВ) | 2.000 x 2.000 x 2.500 |
| Потребление электроэнергии (кВт) | 3 |
| Объем каждого бакового отсека | 1000 |
| Подающий насос, расход (м3 / ч) | 10 |
| Количество дозирующих насосов и питающих емкостей | 1 |
| Расход пара в установке (кг / ч) (1) | 720 |
| Давление пара в установке (бар изб.) | 3-8 |
| Расход очищенной воды за цикл (л) | 2000 |
| Давление очищенной воды (бар изб.) (2) | 2 |
| Подающий насос, давление (бар) | 4 |
Characteristics
Быстрый просмотр
RINA flash dryer models operate continuously by spraying slurries or dosing wet solids in a toroidal or straight drying chamber. This technological solution is particularly recommended for products that can be dried at high temperature to flash the liquid.
| Испарение воды кг / ч | 4 |
| Производительность (влажный продукт) кг / ч | 2 |
| Сухой продукт кг / ч | 0,5 |
| До | 6 |
Characteristics
Быстрый просмотр
The LB Series machines are designed for applying self-adhesive labels to cylindrical cans. The containers are fed onto a conveyor and are detected by a sensor, along which a tape of labels wound on a reel is pulled.
For LB Series models, quality control functions are available with an additional barcode sensor, inkjet / laser printers, visual control of the print.| Другие настройки | 2 |
| Размеры | 2700 (Д) x 1050 (Ш) x 1600 (В) мм |
| Вес нетто | 500 кг |
| - Производительность | Макс. 120 банок в минуту |
| Размеры банок | диаметр 30-100 мм, высота 40-200 мм |
| Размеры этикетки | мин. 15x25 мм / макс. 300 (Д) x 100 (Ш) мм |
Characteristics
Быстрый просмотр
The RINA spray dryer models operate continuously by spraying suspensions in a vertical drying tower. This solution is particularly recommended for heat sensitive pumpable products that require gentle and prolonged drying to obtain a dry powder of fine particles that can be further encapsulated.
| Испарение воды мин. кг / ч | 290 |
| Испарение воды макс. кг / ч | 390 |
Characteristics
Быстрый просмотр
The C2D Automatic Inspection Machine is a reliable and efficient system for visual inspection of a wide range of ampoules and vials for impurities and external defects, with increased productivity.
Image processing is performed using a special algorithm based on the Convel "Fast Vision" machine vision system.| Шум | <75 дБ |
| Вес | прибл. 1500 кг |
| Рабочая высота на входе и выходе | 950 мм ± 25 мм |
| Электропитание | 400 В ± 10% - 50/60 Гц |
| Потребляемая мощность | прибл. 5 кВтч |
| Инженерные системы | сжатый воздух (6 бар для 4,5 м3 / час) |
| Подача | лотками клиента |
| Скорость отжима | прибл. в диапазоне [300 - 3000] об / мин |
| Выдача | в лотки клиентов с точным подсчетом |
| Соответствие | Директива по машинному оборудованию 2006/42 / EC. Программное обеспечение оборудования соответствует требованиям 21 CFR, часть 11. |
Characteristics
Быстрый просмотр
When working with sticky powders, the installation of a hopper with a fluidization system and a crusher allows efficient transfer of powders to further stages of the process without the risk of product retention.
| Другие настройки | 2 |
Characteristics
Быстрый просмотр
MECAS is a fully automatic assembly and capping system that complements the SYFPAC® LVP range where EURO type caps are required. MECAS consists of two units connected to each other by a conveyor belt: 1. The first unit, named T2, assembles the Euro caps onto the container head immediately after placing a drop of water for injection between the cap and the bottle head. This operation contributes to the effective sterilization of the space between the cap and the head of the bottle during the final sterilization. 2. The second and last production station is called 9Z and is designed to seal the vial cap by injection molding. This unit is equipped with separate hot runner injection units to have complete control over each station. The MECAS system is gateless, so there is no plastic waste during production.
| Производительность | до 2.500 единиц в час |
| Тип упаковки | EURO-колпачки |
| Требуемое пространство T2 | 3.8 x 3.4 x 2.7 м |
| Требуемое пространство 9Z | 5.4 x 3.4 x 2.7 м |
Characteristics
Быстрый просмотр
The RINA spray dryer models operate continuously by spraying suspensions in a vertical drying tower. This solution is particularly recommended for heat sensitive pumpable products that require gentle and prolonged drying to obtain a dry powder of fine particles that can be further encapsulated.
| Испарение воды мин. кг / ч | 55 |
| Испарение воды макс. кг / ч | 90 |
Characteristics
Быстрый просмотр
The TF320 automatic blister machine is suitable for medium to large volume production. The main components (forming, sealing, tape pulling units, coding and cutting) are controlled by servo motors.
Coding and cutting units can work with 1, 2 or 3 rows of blister packs, ensuring high production efficiency with minimal material waste.| Производительность | до 600 блистеров / мин |
| Другие настройки | 2 |
| Максимальная глубина формовки | 12 мм |
Characteristics
Быстрый просмотр
The RM series of automatic reciprocating blister machines is suitable for medium to large production volumes and is available in a range of models and designs to suit customer requirements.
The features of the machine are the high flexibility in choosing the layout of the cells of the blister pack and the ability to install various types of feeding systems for the product to be packaged.| Производительность | до 500 блистеров / мин |
| Другие настройки | 2 |
| Максимальная глубина формовки | 12 мм |
Characteristics
Быстрый просмотр
This station is designed for unloading powder from flexible containers (big bags).
Dec's big bag unpacking stations are modular in design to adapt to product characteristics. The construction frame is mounted on load cells, which guarantees accurate dosing.
| Другие настройки | 2 |
Characteristics
Быстрый просмотр
This station is designed for unloading powder from flexible containers (big bags).
Partial emptying of big bags is a problem because it is usually not possible to quickly close a big bag when the outlet is full of product.
The solution is an automated unpacking station where the big bags are unloaded from above with a suction lance connected to the PTS Powder Transfer System®. The spear is automated and without operator intervention allows you to extract the exact required amount of powder from the big bag thanks to weight control through load cells.
| Другие настройки | 2 |
